適用于工業領域中干燥或潮濕環境下的室外電氣連接，也適合偶爾往復移動的彎曲場合或扭轉場合進行敷設。此類產品具有優異的抗UV和耐候性能。廣泛應用于工業自動化設備、設備安裝工程、工業機械、工業空調安裝等領域。若對抗電磁干擾有要求可選用FIC 160 CY。
· 細裸銅絲絞合，符合IEC 60228 5類標準
· 線芯絕緣：改性聚氯乙烯混合物
· 線芯顏色：符合VDE 0293-1
· 線芯層絞成纜
· 外護套：改性聚氯乙烯混合物，黑色RAL 9005
· 阻燃特性符合IEC 60332-1-2
· 耐化學試劑
· 抗UV
· 耐候性
· 耐扭轉
| 型號規格 | 芯數×標稱截面mm² | 標稱外徑mm | 標稱銅重kg/km | 標稱電纜重量kg/km |
| FIC 160 2 X 0.75 | 2 X 0.75 | 8.5 | 14.4 | 81.8 |
| FIC 160 3 G 0.75 | 3 G 0.75 | 9.0 | 21.6 | 93.9 |
| FIC 160 3 X 0.75 | 3 X 0.75 | 9.0 | 21.6 | 93.9 |
| FIC 160 4 G 0.75 | 4 G 0.75 | 9.5 | 29.0 | 109.1 |
| FIC 160 5 G 0.75 | 5 G 0.75 | 10.2 | 36.0 | 127.3 |
| FIC 160 7 G 0.75 | 7 G 0.75 | 11.0 | 51.0 | 163.6 |
| FIC 160 12 G 0.75 | 12 G 0.75 | 13.8 | 86.0 | 238.4 |
| FIC 160 18 G 0.75 | 18 G 0.75 | 15.9 | 130.0 | 337.3 |
| FIC 160 41 G 0.75 | 41 G 0.75 | 22.2 | 296.0 | 720.1 |
| FIC 160 2 X 1 | 2 X 1 | 8.9 | 19.2 | 99.0 |
| FIC 160 3 G 1 | 3 G 1 | 9.3 | 29.0 | 113.1 |
| FIC 160 3 X 1 | 3 X 1 | 9.3 | 29.0 | 113.1 |
| FIC 160 4 G 1 | 4 G 1 | 9.9 | 38.4 | 132.3 |
| FIC 160 4 X 1 | 4 X 1 | 9.9 | 38.4 | 132.3 |
| FIC 160 5 G 1 | 5 G 1 | 10.7 | 48.0 | 153.5 |
| FIC 160 7 G 1 | 7 G 1 | 11.4 | 67.0 | 198.0 |
| FIC 160 12 G 1 | 12 G 1 | 14.4 | 116.0 | 288.9 |
| FIC 160 18 G 1 | 18 G 1 | 16.6 | 173.0 | 423.2 |
| FIC 160 25 G 1 | 25 G 1 | 19.2 | 240.0 | 577.7 |
| FIC 160 34 G 1 | 34 G 1 | 21.9 | 326.0 | 771.6 |
| FIC 160 41 G 1 | 41 G 1 | 23.9 | 394.0 | 899.9 |
| FIC 160 2 X 1.5 | 2 X 1.5 | 9.9 | 29.0 | 124.2 |
| FIC 160 3 G 1.5 | 3 G 1.5 | 10.4 | 43.0 | 145.4 |
| FIC 160 3 X 1.5 | 3 X 1.5 | 10.4 | 43.0 | 145.4 |
| FIC 160 4 G 1.5 | 4 G 1.5 | 11.1 | 58.0 | 171.7 |
| FIC 160 5 G 1.5 | 5 G 1.5 | 12.1 | 72.0 | 201.0 |
| FIC 160 7 G 1.5 | 7 G 1.5 | 13.0 | 101.0 | 263.6 |
| FIC 160 12 G 1.5 | 12 G 1.5 | 16.6 | 173.0 | 403.0 |
| FIC 160 14 G 1.5 | 14 G 1.5 | 17.5 | 202.0 | 452.5 |
| FIC 160 18 G 1.5 | 18 G 1.5 | 19.4 | 259.0 | 552.5 |
| FIC 160 25 G 1.5 | 25 G 1.5 | 22.4 | 360.0 | 777.7 |
| FIC 160 34 G 1.5 | 34 G 1.5 | 25.6 | 490.0 | 1006.0 |
| FIC 160 50 G 1.5 | 50 G 1.5 | 30.7 | 720.0 | 1441.3 |
| FIC 160 2 X 2.5 | 2 X 2.5 | 11.1 | 48.0 | 148.5 |
| FIC 160 3 G 2.5 | 3 G 2.5 | 11.6 | 72.0 | 183.8 |
| FIC 160 4 G 2.5 | 4 G 2.5 | 12.6 | 96.0 | 227.3 |
| FIC 160 4 X 2.5 | 4 X 2.5 | 12.6 | 96.0 | 227.3 |
| FIC 160 5 G 2.5 | 5 G 2.5 | 13.7 | 120.0 | 268.7 |
| FIC 160 7 G 2.5 | 7 G 2.5 | 14.8 | 168.0 | 357.5 |
| FIC 160 12 G 2.5 | 12 G 2.5 | 19.3 | 288.0 | 545.4 |
| FIC 160 14 G 2.5 | 14 G 2.5 | 20.4 | 336.0 | 547.4 |
| FIC 160 18 G 2.5 | 18 G 2.5 | 22.7 | 432.0 | 795.9 |
| FIC 160 25 G 2.5 | 25 G 2.5 | 26.6 | 600.0 | 1104.9 |
| FIC 160 4 G 4 | 4 G 4 | 14.2 | 154.0 | 327.2 |
| FIC 160 5 G 4 | 5 G 4 | 15.6 | 192.0 | 388.9 |
| FIC 160 7 G 4 | 7 G 4 | 16.9 | 269.0 | 518.1 |
| FIC 160 4 G 6 | 4 G 6 | 15.6 | 230.0 | 446.4 |
| FIC 160 5 G 6 | 5 G 6 | 17.3 | 288.0 | 531.3 |
| FIC 160 7 G 6 | 7 G 6 | 18.7 | 403.0 | 712.1 |
| FIC 160 4 G 10 | 4 G 10 | 19.3 | 384.0 | 714.1 |
| FIC 160 5 G 10 | 5 G 10 | 21.3 | 480.0 | 889.8 |
| FIC 160 4 G 16 | 4 G 16 | 21.9 | 614.0 | 1111.0 |
| FIC 160 5 G 16 | 5 G 16 | 24.3 | 768.0 | 1616.0 |
| FIC 160 7 G 16 | 7 G 16 | 27.0 | 1075.0 | 1908.9 |
| FIC 160 4 G 25 | 4 G 25 | 27.0 | 960.0 | 1616.0 |
| FIC 160 5 G 25 | 5 G 25 | 29.9 | 1200.0 | 2070.5 |
| FIC 160 4 G 35 | 4 G 35 | 30.0 | 1344.0 | 2424.0 |
| FIC 160 5 G 35 | 5 G 35 | 33.5 | 1680.0 | 2929.0 |
| FIC 160 4 G 50 | 4 G 50 | 36.7 | 1920.0 | 3434.0 |
| FIC 160 4 G 70 | 4 G 70 | 41.9 | 2688.0 | 5100.5 |
| FIC 160 4 G 95 | 4 G 95 | 48.2 | 3648.0 | 6070.1 |
| FIC 160 4 G 120 | 4 G 120 | 55.1 | 4608.0 | 7575.0 |
