適用于工業領域中干燥或潮濕環境下室內的電氣連接，銅絲編織屏蔽使電纜適應對抗電磁干擾要求較高的場合。產品廣泛應用于工業自動化設備、測控設備、加熱設備、制冷設備、運輸行業、化工行業、冶金行業、新能源等。若安裝空間局限，可選用FIC 125 CY。
· 細裸銅絲絞合，符合IEC 60228 5類標準
· 線芯絕緣：改性聚氯乙烯混合物
· 線芯顏色：符合VDE 0293-1
· 線芯層絞成纜
· 內襯層：改性聚氯乙烯混合物，灰色 RAL 7001
· 屏蔽：鍍錫銅絲編織屏蔽，編織密度約85%
· 外護套：改性聚氯乙烯混合物，（透明或灰色RAL 7001）
· 阻燃特性符合IEC 60332-1-2
· 耐化學試劑
· 輕度耐油
· EMC電兼容性
| 型號規格 | 芯數×標稱截面mm² | 標稱外徑mm | 標稱銅重kg/km | 標稱電纜重量kg/km |
| FIC 120 CY 2 X 0.5 | 2 X 0.5 | 7.2 | 41.0 | 75.8 |
| FIC 120 CY 3 G 0.5 | 3 G 0.5 | 7.5 | 45.5 | 83.8 |
| FIC 120 CY 3 X 0.5 | 3 X 0.5 | 7.5 | 45.5 | 83.8 |
| FIC 120 CY 4 G 0.5 | 4 G 0.5 | 8.1 | 55.0 | 100.0 |
| FIC 120 CY 4 X 0.5 | 4 X 0.5 | 8.1 | 55.0 | 100.0 |
| FIC 120 CY 5 G 0.5 | 5 G 0.5 | 8.7 | 66.0 | 113.1 |
| FIC 120 CY 5 X 0.5 | 5 X 0.5 | 8.7 | 66.0 | 113.1 |
| FIC 120 CY 7 G 0.5 | 7 G 0.5 | 9.2 | 80.5 | 133.3 |
| FIC 120 CY 7 X 0.5 | 7 X 0.5 | 9.2 | 80.5 | 133.3 |
| FIC 120 CY 12 G 0.5 | 12 G 0.5 | 11.6 | 138.5 | 204.0 |
| FIC 120 CY 12 X 0.5 | 12 X 0.5 | 11.6 | 138.5 | 204.0 |
| FIC 120 CY 18 G 0.5 | 18 G 0.5 | 13.7 | 156.4 | 291.9 |
| FIC 120 CY 25 G 0.5 | 25 G 0.5 | 15.7 | 250.0 | 381.8 |
| FIC 120 CY 30 G 0.5 | 30 G 0.5 | 16.6 | 297.0 | 433.3 |
| FIC 120 CY 40 G 0.5 | 40 G 0.5 | 18.7 | 343.0 | 547.4 |
| FIC 120 CY 2 X 0.75 | 2 X 0.75 | 7.6 | 46.0 | 86.9 |
| FIC 120 CY 3 G 0.75 | 3 G 0.75 | 8.1 | 57.9 | 101.0 |
| FIC 120 CY 3 X 0.75 | 3 X 0.75 | 8.1 | 57.9 | 101.0 |
| FIC 120 CY 4 G 0.75 | 4 G 0.75 | 8.7 | 64.0 | 116.2 |
| FIC 120 CY 4 X 0.75 | 4 X 0.75 | 8.7 | 64.0 | 116.2 |
| FIC 120 CY 5 G 0.75 | 5 G 0.75 | 9.2 | 77.4 | 131.3 |
| FIC 120 CY 5 X 0.75 | 5 X 0.75 | 9.2 | 77.4 | 131.3 |
| FIC 120 CY 7 G 0.75 | 7 G 0.75 | 10.0 | 102.0 | 162.6 |
| FIC 120 CY 7 X 0.75 | 7 X 0.75 | 10.0 | 102.0 | 162.6 |
| FIC 120 CY 12 G 0.75 | 12 G 0.75 | 12.7 | 177.0 | 249.5 |
| FIC 120 CY 12 X 0.75 | 12 X 0.75 | 12.7 | 177.0 | 249.5 |
| FIC 120 CY 18 G 0.75 | 18 G 0.75 | 14.9 | 243.0 | 359.6 |
| FIC 120 CY 18 X 0.75 | 18 X 0.75 | 14.9 | 243.0 | 359.6 |
| FIC 120 CY 25 G 0.75 | 25 G 0.75 | 17.1 | 307.3 | 469.7 |
| FIC 120 CY 34 G 0.75 | 34 G 0.75 | 19.5 | 323.2 | 607.0 |
| FIC 120 CY 40 X 0.75 | 40 X 0.75 | 21.1 | 369.4 | 741.3 |
| FIC 120 CY 41 G 0.75 | 41 G 0.75 | 21.2 | 488.0 | 735.3 |
| FIC 120 CY 2 X 1 | 2 X 1 | 8.1 | 56.0 | 99.0 |
| FIC 120 CY 3 G 1 | 3 G 1 | 8.4 | 65.3 | 112.1 |
| FIC 120 CY 3 X 1 | 3 X 1 | 8.4 | 65.3 | 112.1 |
| FIC 120 CY 4 G 1 | 4 G 1 | 9.0 | 78.1 | 131.3 |
| FIC 120 CY 4 X 1 | 4 X 1 | 9.0 | 78.1 | 131.3 |
| FIC 120 CY 5 G 1 | 5 G 1 | 9.8 | 89.4 | 154.5 |
| FIC 120 CY 7 G 1 | 7 G 1 | 10.5 | 113.3 | 186.9 |
| FIC 120 CY 12 G 1 | 12 G 1 | 13.7 | 188.1 | 310.1 |
| FIC 120 CY 16 G 1 | 16 G 1 | 15.0 | 216.0 | 393.9 |
| FIC 120 CY 18 G 1 | 18 G 1 | 16.0 | 286.0 | 422.2 |
| FIC 120 CY 25 G 1 | 25 G 1 | 18.0 | 388.5 | 549.4 |
| FIC 120 CY 34 G 1 | 34 G 1 | 20.9 | 505.0 | 745.4 |
| FIC 120 CY 41 G 1 | 41 G 1 | 22.7 | 578.0 | 872.6 |
| FIC 120 CY 50 G 1 | 50 G 1 | 24.5 | 688.0 | 1021.1 |
| FIC 120 CY 2 X 1.5 | 2 X 1.5 | 8.8 | 65.0 | 118.2 |
| FIC 120 CY 3 G 1.5 | 3 G 1.5 | 9.2 | 83.0 | 137.4 |
| FIC 120 CY 3 X 1.5 | 3 X 1.5 | 9.2 | 83.0 | 137.4 |
| FIC 120 CY 4 G 1.5 | 4 G 1.5 | 9.9 | 100.0 | 164.6 |
| FIC 120 CY 4 X 1.5 | 4 X 1.5 | 9.9 | 100.0 | 164.6 |
| FIC 120 CY 5 G 1.5 | 5 G 1.5 | 10.6 | 125.0 | 189.9 |
| FIC 120 CY 5 X 1.5 | 5 X 1.5 | 10.6 | 125.0 | 189.9 |
| FIC 120 CY 7 G 1.5 | 7 G 1.5 | 11.6 | 149.0 | 239.4 |
| FIC 120 CY 7 X 1.5 | 7 X 1.5 | 11.6 | 149.0 | 239.4 |
| FIC 120 CY 12 G 1.5 | 12 G 1.5 | 15.2 | 280.0 | 396.9 |
| FIC 120 CY 18 G 1.5 | 18 G 1.5 | 17.7 | 389.0 | 543.4 |
| FIC 120 CY 25 G 1.5 | 25 G 1.5 | 20.7 | 535.0 | 752.5 |
| FIC 120 CY 34 G 1.5 | 34 G 1.5 | 23.5 | 702.0 | 973.6 |
| FIC 120 CY 41 G 1.5 | 41 G 1.5 | 25.4 | 844.6 | 1134.2 |
| FIC 120 CY 50 G 1.5 | 50 G 1.5 | 27.9 | 1006.0 | 1385.7 |
| FIC 120 CY 2 X 2.5 | 2 X 2.5 | 10.2 | 112.0 | 166.7 |
| FIC 120 CY 3 G 2.5 | 3 G 2.5 | 10.6 | 146.0 | 193.9 |
| FIC 120 CY 4 G 2.5 | 4 G 2.5 | 11.6 | 167.0 | 235.3 |
| FIC 120 CY 5 G 2.5 | 5 G 2.5 | 13.0 | 200.0 | 285.8 |
| FIC 120 CY 7 G 2.5 | 7 G 2.5 | 14.3 | 288.0 | 374.7 |
| FIC 120 CY 12 G 2.5 | 12 G 2.5 | 18.1 | 477.3 | 590.9 |
| FIC 120 CY 2 X 4 | 2 X 4 | 11.7 | 120.0 | 249.5 |
| FIC 120 CY 4 G 4 | 4 G 4 | 13.8 | 237.0 | 350.5 |
| FIC 120 CY 5 G 4 | 5 G 4 | 15.1 | 280.0 | 417.1 |
| FIC 120 CY 2 X 6 | 2 X 6 | 14.0 | 180.0 | 356.5 |
| FIC 120 CY 4 G 6 | 4 G 6 | 16.3 | 318.0 | 489.9 |
| FIC 120 CY 5 G 6 | 5 G 6 | 17.8 | 441.0 | 709.0 |
| FIC 120 CY 7 G 6 | 7 G 6 | 19.4 | 530.0 | 959.5 |
| FIC 120 CY 2 X 10 | 2 X 10 | 16.9 | 256.0 | 496.9 |
| FIC 120 CY 3 G 10 | 3 G 10 | 17.9 | 362.4 | 512.1 |
| FIC 120 CY 4 G 10 | 4 G 10 | 19.6 | 518.0 | 742.4 |
| FIC 120 CY 5 G 10 | 5 G 10 | 21.9 | 595.0 | 855.5 |
| FIC 120 CY 7 G 10 | 7 G 10 | 23.9 | 796.0 | 1049.4 |
| FIC 120 CY 2 X 16 | 2 X 16 | 19.2 | 390.0 | 705.0 |
| FIC 120 CY 4 G 16 | 4 G 16 | 22.9 | 804.0 | 1409.0 |
| FIC 120 CY 5 G 16 | 5 G 16 | 25.1 | 935.0 | 1454.4 |
| FIC 120 CY 4 G 25 | 4 G 25 | 27.7 | 1161.0 | 1747.3 |
| FIC 120 CY 5 G 25 | 5 G 25 | 30.9 | 1400.0 | 2110.9 |
| FIC 120 CY 4 G 35 | 4 G 35 | 31.1 | 1543.0 | 2232.1 |
| FIC 120 CY 5 G 35 | 5 G 35 | 34.2 | 1901.0 | 2737.1 |
