高柔性控制拖鏈電纜，改性聚氯乙烯混合物外護
應用于工業自動化、機電成套設備、自動物流系統、裝配線、傳感系統、控制設備和控制工程等領域需要以一定速度頻繁移動的機械部件或動力拖鏈系統，作控制電纜使用，用于測量、控制和電路調配。適用于室內或室外干燥或潮濕的區域。特殊結構設計和先進材料的應用，確保電纜具備長使用壽命及高穩定性。若對抗電磁干擾有要求可選用FIDC 660 CY，對耐磨耐油有要求可選用FIDC 660 P。
· 超細裸銅絲絞合，符合IEC 60228 6類標準
· 線芯絕緣：改性聚氯乙烯混合物
· 線芯顏色：符合VDE 0293-1
· 線芯依照獨特的節距控制方案絞合成纜，無紡布繞包
· 外護套：改性聚氯乙烯混合物，灰色 RAL 7001
· 阻燃特性符合IEC 60332-1-2
· 耐化學試劑
· 抗UV
· 500萬次彎曲循環，拖鏈行程10m
| 型號規格 | 芯數×標稱截面mm² | 標稱外徑 mm | 標稱銅重 kg/km | 標稱電纜重量kg/km |
| FIDC 660 2 X 0.5 | 2 X 0.5 | 5.5 | 10.0 | 40.4 |
| FIDC 660 3 G 0.5 | 3 G 0.5 | 5.9 | 15.0 | 48.5 |
| FIDC 660 4 G 0.5 | 4 G 0.5 | 6.5 | 19.2 | 58.6 |
| FIDC 660 5 G 0.5 | 5 G 0.5 | 7.0 | 24.0 | 67.7 |
| FIDC 660 7 G 0.5 | 7 G 0.5 | 8.2 | 34.0 | 88.9 |
| FIDC 660 12 G 0.5 | 12 G 0.5 | 9.8 | 58.0 | 137.4 |
| FIDC 660 18 G 0.5 | 18 G 0.5 | 11.7 | 86.4 | 197.0 |
| FIDC 660 25 G 0.5 | 25 G 0.5 | 14.1 | 120.0 | 276.7 |
| FIDC 660 30 G 0.5 | 30 G 0.5 | 14.7 | 144.0 | 315.1 |
| FIDC 660 34 G 0.5 | 34 G 0.5 | 16.1 | 164.0 | 362.6 |
| FIDC 660 50 G 0.5 | 50 G 0.5 | 19.1 | 240.0 | 520.2 |
| FIDC 660 2 X 0.75 | 2 X 0.75 | 5.9 | 15.0 | 49.5 |
| FIDC 660 3 G 0.75 | 3 G 0.75 | 6.4 | 22.0 | 60.6 |
| FIDC 660 4 G 0.75 | 4 G 0.75 | 7.0 | 29.0 | 73.7 |
| FIDC 660 5 G 0.75 | 5 G 0.75 | 7.6 | 37.0 | 86.9 |
| FIDC 660 7 G 0.75 | 7 G 0.75 | 9.2 | 51.0 | 118.2 |
| FIDC 660 12 G 0.75 | 12 G 0.75 | 10.9 | 87.0 | 182.8 |
| FIDC 660 16 G 0.75 | 16 G 0.75 | 12.4 | 116.0 | 236.3 |
| FIDC 660 18 G 0.75 | 18 G 0.75 | 13.1 | 130.0 | 261.6 |
| FIDC 660 25 G 0.75 | 25 G 0.75 | 15.7 | 181.0 | 366.6 |
| FIDC 660 2 X 1 | 2 X 1 | 6.3 | 19.0 | 58.6 |
| FIDC 660 3 G 1 | 3 G 1 | 6.8 | 29.0 | 72.7 |
| FIDC 660 4 G 1 | 4 G 1 | 7.5 | 39.0 | 88.9 |
| FIDC 660 5 G 1 | 5 G 1 | 8.2 | 48.0 | 105.0 |
| FIDC 660 7 G 1 | 7 G 1 | 9.9 | 67.0 | 143.4 |
| FIDC 660 12 G 1 | 12 G 1 | 11.7 | 115.0 | 223.2 |
| FIDC 660 14 G 1 | 14 G 1 | 12.7 | 134.4 | 260.6 |
| FIDC 660 16 G 1 | 16 G 1 | 13.4 | 153.0 | 289.9 |
| FIDC 660 18 G 1 | 18 G 1 | 14.3 | 173.0 | 327.2 |
| FIDC 660 25 G 1 | 25 G 1 | 16.9 | 240.0 | 449.5 |
| FIDC 660 26 G 1 | 26 G 1 | 16.9 | 249.6 | 463.6 |
| FIDC 660 34 G 1 | 34 G 1 | 19.5 | 326.4 | 601.0 |
| FIDC 660 41 G 1 | 41 G 1 | 21.2 | 394.0 | 719.1 |
| FIDC 660 50 G 1 | 50 G 1 | 23.0 | 480.0 | 862.5 |
| FIDC 660 65 G 1 | 65 G 1 | 26.2 | 624.0 | 1108.0 |
| FIDC 660 2 X 1.5 | 2 X 1.5 | 7.0 | 29.0 | 74.7 |
| FIDC 660 3 G 1.5 | 3 G 1.5 | 7.6 | 43.2 | 93.9 |
| FIDC 660 4 G 1.5 | 4 G 1.5 | 8.3 | 58.0 | 115.1 |
| FIDC 660 5 G 1.5 | 5 G 1.5 | 9.4 | 72.0 | 140.4 |
| FIDC 660 7 G 1.5 | 7 G 1.5 | 11.2 | 101.0 | 190.9 |
| FIDC 660 12 G 1.5 | 12 G 1.5 | 13.3 | 173.0 | 298.0 |
| FIDC 660 18 G 1.5 | 18 G 1.5 | 16.1 | 259.0 | 433.3 |
| FIDC 660 25 G 1.5 | 25 G 1.5 | 19.2 | 360.0 | 603.0 |
| FIDC 660 26 G 1.5 | 26 G 1.5 | 19.2 | 374.4 | 621.2 |
| FIDC 660 34 G 1.5 | 34 G 1.5 | 21.7 | 489.6 | 790.8 |
| FIDC 660 41 G 1.5 | 41 G 1.5 | 23.7 | 613.0 | 945.4 |
| FIDC 660 42 G 1.5 | 42 G 1.5 | 23.7 | 629.0 | 963.5 |
| FIDC 660 50 G 1.5 | 50 G 1.5 | 25.8 | 720.0 | 1145.3 |
| FIDC 660 3 G 2.5 | 3 G 2.5 | 9.3 | 72.0 | 146.5 |
| FIDC 660 4 G 2.5 | 4 G 2.5 | 10.3 | 96.0 | 180.8 |
| FIDC 660 5 G 2.5 | 5 G 2.5 | 11.5 | 120.0 | 220.2 |
| FIDC 660 7 G 2.5 | 7 G 2.5 | 14.0 | 168.0 | 306.0 |
| FIDC 660 12 G 2.5 | 12 G 2.5 | 16.5 | 288.0 | 477.7 |
| FIDC 660 14 G 2.5 | 14 G 2.5 | 17.7 | 336.0 | 553.5 |
| FIDC 660 3 G 4 | 3 G 4 | 10.9 | 120.0 | 216.1 |
| FIDC 660 4 G 4 | 4 G 4 | 12.1 | 160.0 | 268.7 |
| FIDC 660 5 G 4 | 5 G 4 | 13.5 | 200.0 | 328.3 |
| FIDC 660 4 G 6 | 4 G 6 | 14.3 | 230.4 | 400.0 |
| FIDC 660 5 G 6 | 5 G 6 | 16.0 | 288.0 | 488.8 |
| FIDC 660 4 G 10 | 4 G 10 | 18.1 | 384.0 | 650.4 |
| FIDC 660 5 G 10 | 5 G 10 | 20.2 | 480.0 | 792.9 |
| FIDC 660 4 G 16 | 4 G 16 | 21.6 | 615.0 | 931.2 |
| FIDC 660 5 G 16 | 5 G 16 | 24.3 | 768.0 | 1144.3 |
