應用于機器、機械加工、裝配生產線、機床、輸送產線、傳感系統、控制設備和控制工程等領域，用于拖鏈系統或可自由移動的機器部件中，用作控制電纜，用于電路系統的測控與調節。選用先進材料，電纜具有較高的柔性以及耐磨性等特性，適用于存在有害礦物質油類以及耐化學試劑和機械性能要求較高的場景。在-40oC以下保持較高柔性。若對抗電磁干擾有要求可選用FIDC 680 CP。
· 超細裸銅絲絞合，符合IEC 60228 6類標準
· 線芯絕緣：TPE
· 線芯顏色：符合VDE 0293-1
· 線芯絞合成纜，無紡布繞包
· 外護套：改性聚氨酯（PUR）、灰色 RAL 7001
· 阻燃特性符合IEC 60332-1-2，無鹵
· 高度耐油
· 抗UV
· 耐化學試劑
· 耐磨、耐擠壓、抗拉能力、彎曲韌性高
· 耐低溫（≤-40oC）
· 1000萬次彎曲循環，拖鏈行程100m
參考VDE 0281設計
| 型號規格 | 芯數×標稱截面mm² | 標稱外徑 mm | 標稱銅重 kg/km | 標稱電纜重量kg/km |
| FIDC 680 P 2 X 0.5 | 2 X 0.5 | 5.3 | 10.0 | 34.3 |
| FIDC 680 P 3 G 0.5 | 3 G 0.5 | 5.7 | 14.0 | 40.4 |
| FIDC 680 P 5 G 0.5 | 5 G 0.5 | 6.8 | 24.0 | 55.6 |
| FIDC 680 P 6 G 0.5 | 6 G 0.5 | 7.3 | 29.0 | 63.6 |
| FIDC 680 P 7 G 0.5 | 7 G 0.5 | 7.9 | 34.0 | 76.8 |
| FIDC 680 P 12 G 0.5 | 12 G 0.5 | 9.4 | 58.0 | 115.1 |
| FIDC 680 P 18 G 0.5 | 18 G 0.5 | 11.2 | 86.0 | 166.7 |
| FIDC 680 P 20 G 0.5 | 20 G 0.5 | 11.8 | 96.0 | 181.8 |
| FIDC 680 P 25 G 0.5 | 25 G 0.5 | 13.8 | 120.0 | 221.2 |
| FIDC 680 P 30 G 0.5 | 30 G 0.5 | 14.0 | 144.0 | 253.5 |
| FIDC 680 P 36 G 0.5 | 36 G 0.5 | 15.1 | 173.0 | 292.9 |
| FIDC 680 P 2 X 0.75 | 2 X 0.75 | 5.8 | 14.0 | 42.4 |
| FIDC 680 P 3 G 0.75 | 3 G 0.75 | 6.2 | 22.0 | 50.5 |
| FIDC 680 P 4 G 0.75 | 4 G 0.75 | 6.9 | 29.0 | 60.6 |
| FIDC 680 P 5 G 0.75 | 5 G 0.75 | 7.5 | 36.0 | 71.7 |
| FIDC 680 P 7 G 0.75 | 7 G 0.75 | 9.1 | 50.0 | 100.0 |
| FIDC 680 P 12 G 0.75 | 12 G 0.75 | 10.6 | 86.0 | 159.6 |
| FIDC 680 P 18 G 0.75 | 18 G 0.75 | 12.8 | 130.0 | 221.2 |
| FIDC 680 P 20 G 0.75 | 20 G 0.75 | 13.7 | 144.0 | 242.4 |
| FIDC 680 P 25 G 0.75 | 25 G 0.75 | 16.0 | 180.0 | 312.1 |
| FIDC 680 P 36 G 0.75 | 36 G 0.75 | 17.4 | 259.0 | 415.1 |
| FIDC 680 P 2 X 1 | 2 X 1 | 6.2 | 19.0 | 50.5 |
| FIDC 680 P 3 G 1 | 3 G 1 | 6.7 | 29.0 | 61.6 |
| FIDC 680 P 4 G 1 | 4 G 1 | 7.4 | 38.0 | 70.7 |
| FIDC 680 P 5 G 1 | 5 G 1 | 8.0 | 48.0 | 93.9 |
| FIDC 680 P 7 G 1 | 7 G 1 | 9.8 | 67.0 | 123.2 |
| FIDC 680 P 12 G 1 | 12 G 1 | 11.5 | 115.0 | 198.0 |
| FIDC 680 P 18 G 1 | 18 G 1 | 14.1 | 173.0 | 276.7 |
| FIDC 680 P 20 G 1 | 20 G 1 | 14.8 | 192.0 | 303.0 |
| FIDC 680 P 25 G 1 | 25 G 1 | 17.3 | 240.0 | 388.9 |
| FIDC 680 P 30 G 1 | 30 G 1 | 17.5 | 288.0 | 448.4 |
| FIDC 680 P 36 G 1 | 36 G 1 | 19.2 | 346.0 | 521.2 |
| FIDC 680 P 2 X 1.5 | 2 X 1.5 | 6.9 | 29.0 | 68.7 |
| FIDC 680 P 3 G 1.5 | 3 G 1.5 | 7.5 | 43.0 | 83.8 |
| FIDC 680 P 4 G 1.5 | 4 G 1.5 | 8.2 | 58.0 | 101.0 |
| FIDC 680 P 5 G 1.5 | 5 G 1.5 | 9.3 | 72.0 | 129.3 |
| FIDC 680 P 7 G 1.5 | 7 G 1.5 | 11.0 | 101.0 | 178.8 |
| FIDC 680 P 12 G 1.5 | 12 G 1.5 | 13.1 | 173.0 | 277.8 |
| FIDC 680 P 18 G 1.5 | 18 G 1.5 | 15.7 | 259.0 | 409.1 |
| FIDC 680 P 25 G 1.5 | 25 G 1.5 | 19.4 | 360.0 | 570.7 |
| FIDC 680 P 30 G 1.5 | 30 G 1.5 | 19.4 | 432.0 | 658.5 |
| FIDC 680 P 36 G 1.5 | 36 G 1.5 | 21.2 | 518.0 | 766.6 |
| FIDC 680 P 41 G 1.5 | 41 G 1.5 | 23.1 | 614.0 | 987.8 |
| FIDC 680 P 3 G 2.5 | 3 G 2.5 | 9.2 | 72.0 | 122.2 |
| FIDC 680 P 4 G 2.5 | 4 G 2.5 | 10.2 | 96.0 | 164.6 |
| FIDC 680 P 5 G 2.5 | 5 G 2.5 | 11.3 | 120.0 | 198.0 |
| FIDC 680 P 7 G 2.5 | 7 G 2.5 | 13.8 | 168.0 | 268.7 |
| FIDC 680 P 12 G 2.5 | 12 G 2.5 | 16.3 | 288.0 | 450.5 |
| FIDC 680 P 18 G 2.5 | 18 G 2.5 | 19.5 | 432.0 | 671.7 |
| FIDC 680 P 25 G 2.5 | 25 G 2.5 | 24.2 | 600.0 | 938.3 |
