適用于工業領域中干燥或潮濕環境下室內或室外的電氣連接，該電纜在有潛在火災危險的區域或設備、重要資產集中以及人口密度較大的區域尤其適用。產品廣泛應用于工業自動化設備、測控設備、加熱設備、制冷設備、運輸行業、化工行業、冶金行業、新能源等。該產品選用特殊無鹵混合物材料，并結合獨特結構設計，產品極其柔軟，便于安裝和使用。鍍錫銅絲屏蔽結構，滿足應用場景對抗電磁干擾的要求。
?細裸銅絲絞合，符合IEC 60228 5類標準
?線芯顏色符合VDE 0293-1
?線芯層絞成纜
?內護套：改性無鹵混合物，灰色RAL 7001
?屏蔽：鍍錫銅絲編織屏蔽，編織密度85%
?外護套：改性無鹵混合物，灰色RAL 7001
?阻燃特性符合IEC 60332-1-2
?無鹵特性符合IEC 60754-1
?燃燒氣體腐蝕特性符合IEC 60754-2
?煙密度符合IEC 61034-2
?耐化學試劑
?輕度耐油，符合EN 50290-2-22（TM54）
?抗UV和耐候性符合ISO 4892-2
?耐臭氧符合EN 50396
參考EN 50525-3-11
| 型號規格 | 芯數×標稱截面mm² | 外徑mm | 銅重kg/km | 電纜重量kg/km |
| FIC 120 CH 2×0.5 | 2×0.5 | 7.1 | 29.1 | 85 |
| FIC 120 CH 3G0.5 | 3G0.5 | 7.4 | 35.1 | 95 |
| FIC 120 CH 3×0.5 | 3×0.5 | 7.4 | 35.1 | 95 |
| FIC 120 CH 4G0.5 | 4G0.5 | 8 | 41.4 | 111 |
| FIC 120 CH 4×0.5 | 4×0.5 | 8 | 41.4 | 111 |
| FIC 120 CH 5G0.5 | 5G0.5 | 8.6 | 48 | 126 |
| FIC 120 CH 7G0.5 | 7G0.5 | 9.1 | 59.9 | 148 |
| FIC 120 CH 12G0.5 | 12G0.5 | 11.5 | 91.4 | 226 |
| FIC 120 CH 2×0.75 | 2×0.75 | 7.7 | 35.4 | 101 |
| FIC 120 CH 3G0.75 | 3G0.75 | 8 | 43.8 | 114 |
| FIC 120 CH 3×0.75 | 3×0.75 | 8 | 43.8 | 114 |
| FIC 120 CH 4G0.75 | 4G0.75 | 8.5 | 52.8 | 130 |
| FIC 120 CH 4×0.75 | 4×0.75 | 8.5 | 52.8 | 130 |
| FIC 120 CH 5G0.75 | 5G0.75 | 9.3 | 62.3 | 153 |
| FIC 120 CH 5×0.75 | 5×0.75 | 9.3 | 62.3 | 153 |
| FIC 120 CH 7G0.75 | 7G0.75 | 9.9 | 79.5 | 183 |
| FIC 120 CH 7×0.75 | 7×0.75 | 9.9 | 79.5 | 183 |
| FIC 120 CH 12G0.75 | 12G0.75 | 12.5 | 123.2 | 280 |
| FIC 120 CH 18G0.75 | 18G0.75 | 14.8 | 188.6 | 399 |
| FIC 120 CH 25G0.75 | 25G0.75 | 16.9 | 247.5 | 522 |
| FIC 120 CH 2×1.0 | 2×1.0 | 8 | 41.4 | 112 |
| FIC 120 CH 3G1.0 | 3G1.0 | 8.4 | 52.1 | 127 |
| FIC 120 CH 3×1.0 | 3×1.0 | 8.4 | 52.1 | 127 |
| FIC 120 CH 4G1.0 | 4G1.0 | 8.9 | 73.5 | 157 |
| FIC 120 CH 4×1.0 | 4×1.0 | 8.9 | 73.5 | 157 |
| FIC 120 CH 5G1.0 | 5G1.0 | 9.7 | 83.2 | 171 |
| FIC 120 CH 7G1.0 | 7G1.0 | 10.3 | 97.2 | 210 |
| FIC 120 CH 12G1.0 | 12G1.0 | 13.6 | 168.7 | 347 |
| FIC 120 CH 18G1.0 | 18G1.0 | 15.7 | 235.4 | 474 |
| FIC 120 CH 25G1.0 | 25G1.0 | 17.8 | 312 | 611 |
| FIC 120 CH 41G1.0 | 41G1.0 | 22.4 | 508 | 969 |
| FIC 120 CH 2×1.5 | 2×1.5 | 8.6 | 53.2 | 134 |
| FIC 120 CH 3G1.5 | 3G1.5 | 9 | 69.1 | 155 |
| FIC 120 CH 3×1.5 | 3×1.5 | 9 | 69.1 | 155 |
| FIC 120 CH 4G1.5 | 4G1.5 | 9.8 | 85.8 | 186 |
| FIC 120 CH 5G1.5 | 5G1.5 | 10.5 | 102.8 | 215 |
| FIC 120 CH 7G1.5 | 7G1.5 | 11.4 | 134.2 | 269 |
| FIC 120 CH 12G1.5 | 12G1.5 | 15 | 232.8 | 445 |
| FIC 120 CH 18G1.5 | 18G1.5 | 17.4 | 327.8 | 610 |
| FIC 120 CH 25G1.5 | 25G1.5 | 20.4 | 463.2 | 843 |
| FIC 120 CH 3G2.5 | 3G2.5 | 10.5 | 102.8 | 220 |
| FIC 120 CH 4G2.5 | 4G2.5 | 11.4 | 129.4 | 265 |
| FIC 120 CH 5G2.5 | 5G2.5 | 12.7 | 157.5 | 322 |
| FIC 120 CH 7G2.5 | 7G2.5 | 14 | 223 | 422 |
| FIC 120 CH 12G2.5 | 12G2.5 | 17.9 | 360.5 | 659 |
| FIC 120 CH 4G4.0 | 4G4.0 | 13.6 | 207.6 | 390 |
| FIC 120 CH 5G4.0 | 5G4.0 | 14.9 | 251.5 | 463 |
| FIC 120 CH 7G4.0 | 7G4.0 | 16.2 | 333.9 | 588 |
| FIC 120 CH 4G6.0 | 4G6.0 | 15.8 | 294.8 | 516 |
| FIC 120 CH 5G6.0 | 5G6.0 | 17.3 | 356.1 | 616 |
| FIC 120 CH 7G6.0 | 7G6.0 | 18.8 | 479.3 | 792 |
| FIC 120 CH 4G10.0 | 4G10.0 | 19.1 | 461.1 | 789 |
| FIC 120 CH 5G10.0 | 5G10.0 | 21.4 | 586.6 | 998 |
| FIC 120 CH 4G16.0 | 4G16.0 | 22.3 | 727.6 | 1154 |
| FIC 120 CH 5G16.0 | 5G16.0 | 24.5 | 888.7 | 1389 |
| FIC 120 CH 4G25.0 | 4G25.0 | 27 | 1123.9 | 1807 |
| FIC 120 CH 4G35.0 | 4G35.0 | 30.4 | 1529.2 | 2321 |
