適用于商用車輛、拖車與半拖車中的電氣設備布線。
?細裸銅絲絞合，符合IEC 60228 6類標準
?線芯絕緣：改性聚氯乙烯混合物
?芯線標識：ISO 4141-3
?線芯絞合成纜
?外護套：改性聚氨酯混合物
?耐油
?高機械強度
?耐化學試劑
?耐候性
?抗微生物和水解
?抗UV
參考ISO 6722、ISO 4141
| 型號規(guī)格 | 芯數(shù)×標稱截面mm² | 外徑mm | 銅重kg/km | 電纜重量kg/km |
| FIC 191 P 2×1.0 | 2×1.0 | 6 | 19.2 | 55 |
| FIC 191 P 2×1.5 | 2×1.5 | 6.6 | 28.8 | 68 |
| FIC 191 P 3×1.0 | 3×1.0 | 6.3 | 28.8 | 68 |
| FIC 191 P 4×1.0 | 4×1.0 | 6.8 | 38.4 | 81 |
| FIC 191 P 4×1.5 | 4×1.5 | 7.5 | 57.6 | 106 |
| FIC 191 P 5×1.0 | 5×1.0 | 7.5 | 48 | 97 |
| FIC 191 P 5×1.0+1×2.5 | 5×1.0+1×2.5 | 9 | 72 | 133 |
| FIC 191 P 6×1.5+1×2.5 | 6×1.5+1×2.5 | 10.3 | 110.4 | 187 |
| FIC 191 P 7×0.75 | 7×0.75 | 7.3 | 50.4 | 101 |
| FIC 191 P 7×1.5 | 7×1.5 | 8.9 | 100.8 | 166 |
| FIC 191 P 8×1.5+1×2.5 | 8×1.5+1×2.5 | 11.7 | 139.2 | 239 |
| FIC 191 P 10×1.5+3×2.5+1×2×1.5 |
10×1.5+3×2.5+1×2×1.5 | 14.4 | 244.8 | 391 |
| FIC 191 P 10×1.5+3×2.5 | 10×1.5+3×2.5 | 14.4 | 216 | 367 |
| FIC 191 P 2×0.75+2×1.5 | 2×0.75+2×1.5 | 7.2 | 43.2 | 85 |
| FIC 191 P 18×1.5 | 18×1.5 | 13.7 | 259.2 | 407 |
| FIC 191 P 25×1.5 | 25×1.5 | 16.1 | 360 | 560 |
| FIC 191 P 2×4+3×1.5+1×2×1.5 |
2×4+3×1.5+1×2×1.5 | 12.6 | 135 | 67.5 |
| FIC 191 P 6×1.5+1×2.5 | 6×1.5+1×2.5 | 11 | 97.6 | 57.8 |
| FIC 191 P 2×4+3×1.5 | 2×4+3×1.5 | 11.7 | 109.9 | 62.3 |
| FIC 191 P 6×1.0+1×1.5 | 6×1.0+1×1.5 | 10.8 | 67.5 | 63.2 |
| FIC 191 P 3×2.5+10×1.5+1×2×1.5 |
3×2.5+10×1.5+1×2×1.5 | 15.6 | 217.8 | 93.2 |
