適用于加工設備和機械工業設備以及計算機系統等對抗電磁干擾要求較高的場合，滿足控制和測量技術的需求。此類電纜尺寸較小，專為安裝空間有限的各類工程設計。
· 細裸銅絲絞合，符合IEC 60228 5類標準
· 線芯絕緣：改性聚氯乙烯混合物
· 線芯顏色：符合VDE 0293-1
· 線芯層絞成纜
· 聚酯薄膜繞包
· 鍍錫銅編織屏蔽，覆蓋率約85%
· 外護套：改性聚氯乙烯混合物，（透明或灰色RAL 7001）
· 阻燃特性符合IEC 60332-1-2
· 耐化學試劑
· 電磁兼容
·占用空間小
參考VDE 0245、0281 設計
| 型號規格 | 芯數×標稱截面 mm2 | 標稱外徑 mm | 標稱銅重kg/km | 標稱電纜重量kg/km |
| FIC 135 CY 2 X 0.5 | 2 X 0.5 | 6 | 36 | 45.5 |
| FIC 135 CY 3 G 0.5 | 3 G 0.5 | 6.3 | 43 | 59.6 |
| FIC 135 CY 3 X 0.5 | 3 X 0.5 | 6.3 | 43 | 59.6 |
| FIC 135 CY 4 G 0.5 | 4 G 0.5 | 6.7 | 49 | 71.7 |
| FIC 135 CY 4 X 0.5 | 4 X 0.5 | 6.7 | 49 | 71.7 |
| FIC 135 CY 5 G 0.5 | 5 G 0.5 | 7.2 | 57 | 86.9 |
| FIC 135 CY 5 X 0.5 | 5 X 0.5 | 7.2 | 57 | 86.9 |
| FIC 135 CY 7 G 0.5 | 7 G 0.5 | 7.7 | 69 | 106.1 |
| FIC 135 CY 7 X 0.5 | 7 X 0.5 | 7.7 | 69 | 106.1 |
| FIC 135 CY 12 G 0.5 | 12 G 0.5 | 10.2 | 104 | 202 |
| FIC 135 CY 12 X 0.5 | 12 X 0.5 | 10.2 | 104 | 202 |
| FIC 135 CY 18 G 0.5 | 18 G 0.5 | 11.8 | 141 | 277.8 |
| FIC 135 CY 18 X 0.5 | 18 X 0.5 | 11.8 | 141 | 277.8 |
| FIC 135 CY 25 G 0.5 | 25 G 0.5 | 13.8 | 211 | 353.5 |
| FIC 135 CY 25 X 0.5 | 25 X 0.5 | 13.8 | 211 | 353.5 |
| FIC 135 CY 2 X 0.75 | 2 X 0.75 | 6.4 | 43 | 56.6 |
| FIC 135 CY 3 G 0.75 | 3 G 0.75 | 6.7 | 52 | 70.7 |
| FIC 135 CY 3 X 0.75 | 3 X 0.75 | 6.7 | 52 | 70.7 |
| FIC 135 CY 4 G 0.75 | 4 G 0.75 | 7.2 | 61 | 96 |
| FIC 135 CY 4 X 0.75 | 4 X 0.75 | 7.2 | 61 | 96 |
| FIC 135 CY 5 G 0.75 | 5 G 0.75 | 7.9 | 72 | 109.1 |
| FIC 135 CY 5 X 0.75 | 5 X 0.75 | 7.9 | 72 | 109.1 |
| FIC 135 CY 7 G 0.75 | 7 G 0.75 | 8.5 | 89 | 128.3 |
| FIC 135 CY 7 X 0.75 | 7 X 0.75 | 8.5 | 89 | 128.3 |
| FIC 135 CY 12 G 0.75 | 12 G 0.75 | 11.2 | 138 | 234.3 |
| FIC 135 CY 18 G 0.75 | 18 G 0.75 | 13.1 | 211 | 318.2 |
| FIC 135 CY 25 G 0.75 | 25 G 0.75 | 15.2 | 280 | 439.4 |
| FIC 135 CY 25 X 0.75 | 25 X 0.75 | 15.2 | 280 | 439.4 |
| FIC 135 CY 2 X 1 | 2 X 1 | 6.7 | 51 | 71.7 |
| FIC 135 CY 3 G 1 | 3 G 1 | 7 | 62 | 86.9 |
| FIC 135 CY 3 X 1 | 3 X 1 | 7 | 62 | 86.9 |
| FIC 135 CY 4 G 1 | 4 G 1 | 7.5 | 74 | 99 |
| FIC 135 CY 4 X 1 | 4 X 1 | 7.5 | 74 | 99 |
| FIC 135 CY 5 G 1 | 5 G 1 | 8.3 | 88 | 122.2 |
| FIC 135 CY 5 X 1 | 5 X 1 | 8.3 | 88 | 122.2 |
| FIC 135 CY 7 G 1 | 7 G 1 | 9.1 | 112 | 148.5 |
| FIC 135 CY 7 X 1 | 7 X 1 | 9.1 | 112 | 148.5 |
| FIC 135 CY 12 G 1 | 12 G 1 | 11.8 | 185 | 287.9 |
| FIC 135 CY 18 G 1 | 18 G 1 | 14.3 | 268 | 399 |
| FIC 135 CY 25 G 1 | 25 G 1 | 16.4 | 354 | 490.9 |
| FIC 135 CY 2 X 1.5 | 2 X 1.5 | 7.3 | 65 | 86.9 |
| FIC 135 CY 3 G 1.5 | 3 G 1.5 | 7.7 | 82 | 113.1 |
| FIC 135 CY 3 X 1.5 | 3 X 1.5 | 7.7 | 82 | 113.1 |
| FIC 135 CY 4 G 1.5 | 4 G 1.5 | 8.4 | 100 | 136.4 |
| FIC 135 CY 4 X 1.5 | 4 X 1.5 | 8.4 | 100 | 136.4 |
| FIC 135 CY 5 G 1.5 | 5 G 1.5 | 9.2 | 119 | 149.5 |
| FIC 135 CY 5 X 1.5 | 5 X 1.5 | 9.2 | 119 | 149.5 |
| FIC 135 CY 7 G 1.5 | 7 G 1.5 | 10.2 | 154 | 193.9 |
| FIC 135 CY 7 X 1.5 | 7 X 1.5 | 10.2 | 154 | 193.9 |
| FIC 135 CY 12 G 1.5 | 12 G 1.5 | 13.4 | 268 | 368.7 |
| FIC 135 CY 18 G 1.5 | 18 G 1.5 | 16.1 | 373 | 525.2 |
| FIC 135 CY 25 G 1.5 | 25 G 1.5 | 18.4 | 530 | 741.3 |
| FIC 135 CY 34 G 1.5 | 34 G 1.5 | 21.4 | 683 | 953.4 |
| FIC 135 CY 3 G 2.5 | 3 G 2.5 | 9.2 | 118 | 152.5 |
| FIC 135 CY 4 G 2.5 | 4 G 2.5 | 10.2 | 147 | 189.9 |
| FIC 135 CY 5 G 2.5 | 5 G 2.5 | 11.3 | 176 | 272.7 |
| FIC 135 CY 7 G 2.5 | 7 G 2.5 | 12.3 | 253 | 343.4 |
| FIC 135 CY 12 G 2.5 | 12 G 2.5 | 16.5 | 355 | 545.4 |
| FIC 135 CY 18 G 2.5 | 18 G 2.5 | 19.6 | 569 | 789.8 |
| FIC 135 CY 25 G 2.5 | 25 G 2.5 | 22.9 | 827 | 1371.6 |
| FIC 135 CY 4 G 4 | 4 G 4 | 11.9 | 248 | 308.1 |
| FIC 135 CY 7 G 4 | 7 G 4 | 14.8 | 355 | 505 |
| FIC 135 CY 4 G 6 | 4 G 6 | 14.6 | 343 | 444.4 |
| FIC 135 CY 7 G 6 | 7 G 6 | 17.5 | 505 | 678.7 |
| FIC 135 CY 4 G 10 | 4 G 10 | 17.7 | 495 | 686.8 |
| FIC 135 CY 5 G 10 | 5 G 10 | 20.1 | 592 | 832.2 |
| FIC 135 CY 4 G 16 | 4 G 16 | 20.8 | 800 | 1060.5 |
| FIC 135 CY 5 G 16 | 5 G 16 | 23.3 | 895 | 1297.9 |
| FIC 135 CY 4 G 25 | 4 G 25 | 25.9 | 1075 | 1427.1 |
| FIC 135 CY 5 G 25 | 5 G 25 | 28.8 | 1400 | 1995.8 |
| FIC 135 CY 4 G 35 | 4 G 35 | 28.8 | 1576 | 2090.7 |
